One Piece Two Way Ferrule Ball Valve Stainless Steel 1000Psi

Brand Name : AFK

Model Number : BV

Certification : CE

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000PC

Delivery Time : 1WEEK

Packaging Details : Expotrt Packing

Material : Stainless Steel

Port size : 1/8" 1/4" 3/8" 1/2"

Pressure : Low Pressure

Standard or nonstandard : Standard

Media : Gas

Application : General

Body material : Stainless Steel

Valve type : 2 way

Contact Now

Specification

This multi-purpose manual lever ball valve has excellent corrosion resistance and is fit for many applications. The valve is fitted with PTFE seals for maximizing corrosion resistance and lifespan of the ball valve.
1000 WOG:Max 1000 psi for Water, Oil, Gas
Fluid Medium:For use with liquids and gases
Body & Ball Type:304 Stainless Steel
Temp Range:-60°F to 450°F
Handle:Heavy duty handle with blue vinly insulation

Nominal pressure	Application stable range	Applicable Medium	thread type
1.6Mpa	negative 20~180degree	water, oil, air and other non-corrosive liquid (W.O.G)	G, NPT, BSPT, BSP, DI259/2999

One Piece Two Way Ferrule Ball Valve Stainless Steel 1000Psi

Material

item	part	material
1	body	stainless steel
2	tailpiece	stainless steel
3	ball	stainless steel
4	seat	PTFE
5	stem	stainless steel
6	thrust washer	PTFE
7	gland nut	stainless steel
8	gland packing	PTFE

One Piece Two Way Ferrule Ball Valve Stainless Steel 1000Psi
